Camera IP Dome hồng ngoại 2.0 Megapixel Hanwha Techwin WISENET SNV-6085R/KAP

-Chuẩn nén hình ảnh: H.264, MJPEG.

Danh mục: Camera IP Samsung Wisenet

Mô tả
Sản phẩm liên quan

Camera IP Dome hồng ngoại 2.0 Megapixel Hanwha Techwin WISENET SNV-6085R/KAP

-Cảm biến hình ảnh: 1/2.8 inch CMOS.

-Chuẩn nén hình ảnh: H.264, MJPEG.

-Độ phân giải camera ip: 2.0 Megapixel.

-Hỗ trợ khe cắm thẻ nhớ micro SD/SDHC/SDXC dung lượng lưu trữ 64GB.

-Ống kính: 10 ~ 23mm.

-Tỉ lệ Zoom: 2.3x.

-Góc quan sát theo chiều ngang: 31.3º ~ 13.9º/ theo chiều dọc: 17.1º ~ 7.8º.

-Số đèn LED hồng ngoại: 14 đèn LED hồng ngoại.

-Tầm quan sát hồng ngoại: 20 mét.

-Chức năng quan sát Ngày và Đêm.

Chức năng giảm nhiễu số 2D+3D.

-Chức năng vùng riêng tư: Off / On (4ea 4 points polygonal zones).

-Chức năng phát hiện chuyển động: Off / On (32 zones with 4 points of polygonal).

-Chức năng lọc nhiễu kỹ thuật số Digital DNR (Dynamic Noise Reduction).

-Chức năng chống sương mù Defog.

-Chức năng phân tích Video thông minh.

-Tiêu chuẩn chống thấm nước và bụi: IP66 (thích hợp sử dụng trong nhà và ngoài trời).

-Tiêu chuẩn chống va đập: IK10.

-Nguồn điện cung cấp: 12VDC.

-Chức năng cấp nguồn qua mạng PoE.

-Kích thước: Ø160.0 x 118.5mm.

-Trọng lượng: 970g.

Đặc tính kỹ thuật

Video
Imaging Device	1/2.8 inch CMOS
Total Pixels	1,952(H) x 1,116(V)
Effective Pixels	1,944(H) x 1,104(V)
Scanning System	Progressive
Min. Illumination	Color: 0.25Lux (F1.6, 50IRE), 0.09Lux (F1.6, 30IRE)
Min. Illumination	B/W: 0Lux (F1.6, 50IRE, IR LED on), 0Lux (F1.6, 30IRE, IR LED on)
S / N Ratio	50dB
Video Output	CVBS: 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation
Video Output	DIP connector type
Lens
Focal Length (Zoom Ratio)	10 ~ 23mm (2.3x) motorized varifocal
Max. Aperture Ratio	F1.6
Angular Field of View	H: 31.3° (Wide) ~ 13.9° (Tele) / V: 17.1° (Wide) ~ 7.8° (Tele)
Min. Object Distance	0.8m (2.62ft)
Focus Control	Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus)
Lens Type / Mount Type	P-Iris / Board-in type
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range	0° ~ 354° / 0° ~ 67° / 0° ~ 355°
Operational
IR LED	14ea
Viewable Length	20m
Camera Title	Off / On (Displayed up to 15 characters)
Day & Night	Auto (ICR) / Color / B/W / External / Schedule
Backlight Compensation	Off / BLC
Wide Dynamic Range	120dB
Contrast Enhancement (DWDR)	SSDR (Samsung Super Dynamic Range) (Off / On)
Digital Noise Reduction	SSNRIII (2D+3D noise filter) (Off / On)
Digital Image Stabilization	Off / On
Defog	Off / Auto / Manual
Motion Detection	Off / On (4ea 4 points polygonal zones)
Privacy Masking	Off / On (32 zones with 4 points of polygonal)
Gain Control	Off / Low / Middle / High
White Balance	ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed	Minimum / Maximum / Anti flicker
Flip / Mirror	Off / On
Intelligent Video Analytics	Motion detection with metadata, Tampering, Defocus detection
Alarm I/O	Input 1ea / Output 1ea
Alarm Triggers	Motion detection, Tampering, Audio detection, Face detection, Video analytics, Network disconnection, Alarm input
Alarm Events	File upload via FTP and E-mail, Local storage recording at event, Notification via E-mail, External output
Network
Ethernet	RJ-45 (10/100BASE-T)
Video Compression Format	H.264 (MPEG-4 part 10/AVC), MJPEG
Resolution	1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
Max. Framerate	H.264: Max. 60fps at all resolutions
	MJPEG: 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768: Max. 15fps
	800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180: Max.30fps
Smart Codec	Manual mode (Area-based: 5ea), Face detection mode
Video Quality Adjustment	H.264: Compression level, Target bitrate level control, MJPEG: Quality level control
Streaming Capability	Multiple streaming (Up to 10 profiles)
Bitrate Control Method	H.264: CBR or VBR, MJPEG: VBR
Audio In	Selectable (Mic in / Line in), Max output level: 1 Vrms
Audio In	Supply voltage: 2.5VDC (4mA), Input impedance: approx. 2K Ohm
Audio Out	Line out (3.5mm stereo mini jack)
Audio Compression Format	G.711 u-law / G.726 selectable
Audio Compression Format	G.726 (ADPCM) 8KHz, G.711 8KHz, G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication	Bi-directional audio
IP	IPv4, IPv6
Protocol	TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, NMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Security	HTTPS (SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication
Streaming Method	Unicast / Multicast
Max. User Access	15 users at unicast mode
Storage	micro SD/SDHC/SDXC Max. 64G, NAS – Motion images recorded in the SD/SDHC/SDXC memory card can be downloaded. Manual recording at local PC
Application Programming Interface	ONVIF profile S/G, HTTP API (SUNAPI)
Webpage Language	English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Finnish, Norwegian
Web Viewer	Supported OS: Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 ~ 10.10
Web Viewer	Supported Browser: Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 35), Google Chrome (Ver. 15 ~ 40), Apple Safari (Ver. 8.0.2(Mac OS X 10.10), 7.0.6 (Mac OS X 10.9), 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7) Mac OS X only
Central Management Software	SmartViewer
ELECTRICAL
Input Voltage / Current	12VDC ±10%, 24V AC ±10%, PoE (IEEE802.3af)
Power Consumption	Max. 11W (Heater off), Max. 12.95W (Heater on)
Color/ Material	Ivory / Aluminum
Dimensions	Ø160.0 x 118.5mm
Weight	970g

–Hãng sản xuất: Hanwha Techwin Hàn Quốc.

-Sản xuất tại Korea.

-Bảo hành: 24 tháng.
