Switch Advantech EKI-2706E-1GFPI
4FE PoE+1G+1G SFP, Unmanaged Ethernet Switch, IEEE802.3af/at, 48V~53VDC, -40~75℃
- Supports 10/100/1000 Mbps Auto Negotiation (EKI-2706G)
- Supports jumbo frame transmission up to 9 kbytes
- DIN-rail with IP30 metal mechanism
- Redundant 48 VDC power input
- 4 x IEEE 802.3 af/at PoE ports + 1 x Gigabit Copper + 1 Gigabit SFP ports
The EKI-2706 series support 48VDC redundant power input and is secured with a double protection mechanism: Power Polarity Reverse Protect and an Overload Current Fuse. The EKI-2706 series support up to 4-port IEEE 802.3 af/at PoE /PoE ports, it is more convenient for users to power up their devices. Each port of EKI-2706 has 2 LED’s to show the link status transmission speed and collision status. It also provides a relay output for an event alarm. In the event of a power failure, the built-in LED will activate the alarm to notify administrators. Engineers can simply verify the hardware status by checking the LED, and have troubleshooting easy and quick. EKI-2706 comes with compact metal housing that rates IP30 to help against from dusty industrial environments.
- Part Number
- Details
-
EKI-2706E-1GFPI-AE
- Yes
- Ports Number
- 6
- RJ45 Port Connector Type
- RJ45 Transmission Speed
- RJ45 Transmission Distance
- Fiber Transmission Distance
- 5 x RJ-45 + 1 x SFP ports
- 10/100Base-T(X), 10/100/1000Base-T(X), 100/1000Base SFP Ports
- 100 m
- Up to 110km
- Power Input (DC)
- Power Input (AC)
- Power Operating Current
- Power Consumption
- Power Connector Type
- Reverse Polarity (X)
- 48VDC
- 48 VDC
- 1A @24VDC
- Max 2W
- 6-pin removable screw terminal ((power & relay)
- Present
- Ethernet Standard
- EMI
- Safety
- EMC
- Shock
- Freefall
- Vibration
- IEEE 802.1p, 802.3ad, 802.1x, 802.1D, 802.1s, 802.1w, 802.3af/at
- CE, FCC Class A
- UL 60950
- EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3)
- IEC 60068-2-27
- IEC 60068-2-32
- IEC 60068-2-6
- Description
- Fiber Port Interface (X)
- Fiber Port Description (X)
- 4 x 10/100-BaseT(X) + 1 x 10/100/1000Base-T(X)
- SFP
- 1 x SFP(mini-GBIC)port
- PoE Port Number
- 4
- MAC Table Size
- Packet Buffer Size
- Switch Fabric Speed
- Jumbo Frame
- 2K
- 1M bit
- 4.8Gbps
- 9,216 bytes
- Dimensions (W x H x D)
- IP Rating
- Enclosure (Metal)
- Weight
- Mounting (X)
- 30 x 140 x 95 mm (1.18″ x 5.51″ x 3.74″)
- IP30
- Metal
- 0.45 Kg
- DIN-rail, Wall
- Temperature (Operating Range)
- Temperature (Storage Range)
- Relative Humidity
- -40 ~ 75°C (-40 ~ 167°F)
- -40 ~ 85°C (-40 ~ 185°F)
- 10 ~ 95%
- Time
- Method
- 1,697,086 hours
- Telcordia(Relax), GB
- Warranty Period
- 5 years
