Antaira FCU-3002A-SC-S2

Antaira Technologies FCU-3002A-SC-S2 is a compact, single-mode Gigabit Ethernet converter. The FCU-3002A-SC-S2 will take 10/100/1000BaseT copper Ethernet and convert it to 1000BaseX fiber. The FCU-3002A-SC-S2 features a standard SC fiber connector as well
as the STP-RJ45 Ethernet connector. The copper media converter is fully compliant with IEEE 802.3z and 802.3u Fast Ethernet standers. The industrial media converter features LED diagnostics for power, activity, link and Full/Half Duplex operations. The FCU-3002A-SC-S2
gigabit media converter will use single mode 1310NM fiber with a SC connector and is capable of communication of up to 20 Kilometers.

• Complies with IEEE 802.3/u/ab 10/100/1000BaseT
• Complies with IEEE 802.3z 1000BaseX
• Supports Jumbo Frame (9K bytes)
• Store-and-Forward Switching Mechanism
• Auto-Crossover for MDI/MDIX in TP Port
• Auto-Negotiation in TP Port
• Supports Flow Control
• Supports Link Alarm
• Supports Auto & Force Mode Configuration
• 5-Year Warranty
