Antaira IMP-C1000-SFP-bt

Antaira Technologies’ IMP-C1000-SFP-bt series is a compact IP30 rated gigabit Ethernet-to-Fiber media converter featuring a 10/100/1000TX Ethernet port that supports IEEE 802.3bt high power PoE supplying up to 90 watts, and has a dual rate 100/1000 SFP slot.
It is perfectly designed to fulfill industrial applications that require distance extension and high bandwidth capabilities. This small form factor is ideal for saving space in outdoor applications such as factory automation, security, ITS transportation,
power/utility, water wastewater treatment plants, and any other extreme ambient weather environments.

The IMP-C1000-SFP-bt series has a built-in PD Remote Reset Technology function (PRRT). The PRRT function allows user to remotely reboot the media converter and reset the connected powered device (PD). The unit also has 48~55VDC redundant power inputs with
reverse polarity and overload current protection. This product series supports DIN-rail as well as wall mountable orientations and there are two operating temperature range models in STD: -10°C to 65°C and EOT: -40°C to 75°C

• 1-Port 10/100/1000Tx RJ45 with IEEE 802.3bt Compliant PoE
• 1-Port 100/1000Fx SFP Slot
• Link Fault Pass-Through (LFP) Function Support
• Operating Temperature Range: STD: -10° to 65°
• 5-Year Warranty
