Antaira LNP-1002C-SFP-24-T

Antaira’s LNP-1002C-SFP-24-T 10 port industrial PoE+ gigabit unmanaged Ethernet switch is IP30 rated and DIN-Rail mountable. Each unit is embedded with 8* 10/100Tx Ethernet ports that are IEEE 802.3at compliant (power-over-Ethernet plus), and two gigabit
combo port with 2*10/100/1000Tx RJ45 Ethernet ports and dual rate (100/1000) SFP slots, making it ideal for applications that demand high bandwidth and long distance communication.

This model provides high EFT and ESD protection to prevent any unregulated voltage and is suitable for harsh environments. It supports a low voltage power input in a 12~36VDC range with built-in voltage booster, and provides the power redundancy feature
using a dual power input with reverse polarity protection. In addition, the built-in relay warning function alerts maintainers when power failures occur.

LNP-1002C-SFP-24-T supports operating temperature from -40° to 75°C. It is a perfectly designed product to fulfill special needs within industrial automation, outdoor applications and harsh weather environments.

• Supports 8-Port 10/100Tx IEEE 802.3at PoE+ Compliant with 30W per Port, + 2 Gigabit Combo (2*10/100/1000 RJ45, and 2*100/1000 SFP Slots)
• Supports Auto MDI/MDI-X Function
• Non-Blocking Switching Fabric
• 8K MAC Address Table
• Surge Protection: 2,000 VDC Support
• ESD Protection: 6,000 VDC Support
• Redundant Power Input Design: 12~36VDC
• Built-in 1 Relay Output for Power Failure Warning
• IP30 Rugged Metal Case Design
• DIN-Rail and Wall Mount Support
• Operating Temperature Range – EOT: -40° to 75° C
• 5-Year Warranty
