Antaira LNP-1002G-SFP-24

Antaira’s LNP-1002G-SFP-24 industrial gigabit unmanaged Ethernet switch is IP30 rated and DIN-Rail mountable. Each unit is designed with 8 gigabit Ethernet ports that are IEEE 8023.at compliant (power-over-Ethernet plus) and has two dual rate (100/1000)
SFP slots, making it ideal for applications that demand high bandwidth and long distance communication.

LNP-1002G-SFP-24 provides high EFT and ESD protection to prevent any unregulated voltage and is suitable for harsh environments. It supports the power redundancy feature using a dual power input design with reverse polarity protection. In addition, the built-in
relay warning function alerts maintainers when power failures occur.

This model meets IEEE 802.3at (30 Watts per port @ 53VDC), supports 12V ~ 36VDC power inputs and has an operating temperature range of -10 to 70° C. It is a perfectly designed product to fulfill any special needs for industrial automation, outdoor applications
and harsh weather environments.

• Supports 8-Port 10/100/1000Tx IEEE 802.3at PoE+ Compliant with 30W per Port, and 2-Port 100/1000 SFP
• Supports Auto MDI/MDI-X Function
• Store-and-Forward Switching Architecture
• 20Gbps Back-Plane (Switching Fabric)
• 8K MAC Address Table
• 9.6Kbytes Jumbo Frame Support
• Surge Protection: 2,000 VDC Support
• ESD Protection: 6,000 VDC Support
• Redundant Power Input Design: 12~36VDC
• Built-in 1 Relay Output for Power Failure Detection
• IP30 Rugged Metal Case Design
• DIN-Rail and Wall Mount Support
• Operating Temperature Range – STD: -10° to 70° C
• 5-Year Warranty
