Features
• 2 Mega pixel 1/2.9′ SONY progressive scan CMOS
• 3.0mm Wide angle Megapixel Board Lens( Option: 2.8mm)
• Triple Stream
• Supports image resolution up to 2MP
• Supports VBR/CBR in H.264
• Controllable frame rate
• Supports WDR, Defog, 2D+3DNR, Smart IR
• Digital PTZ
• Corridor view in H.264
• Tool-Free 3-Axis
• 12VDC/ IEEE802.3af POE
• Conformant with ONVIF (Profile-S)
• Includes Windows based IP Installer and license-free16 NVR
(Network Video Recorder)
Specification
Model Name |
SVNV50151X |
CPU |
ARM1176JZF-S (400 MHz, Instruction cache: 32kbyte, data cache |
Flash |
2Gbit Flash memory |
SDRAM |
2Gbit DDR3 |
Image sensor |
2.0 Mega 1/2.9′ SONY progressive scan CMOS |
Total Pixels |
1952(H) x 1116(V) 2.18 Megapixel |
Effective Pixels |
1944(H) x 1104(V) 2.14 Megapixel |
S/N Ratio |
More than 50dB |
Min. Illumination |
0.1Lux |
IR Distance |
N/A |
Lens |
3.0mm Wide angle Megapixel Board Lens (Option: 2.8mm) |
Video compression |
H.264 High Profile@4.0, MJPEG–Image quality: 3 Steps |
Resolutions |
Up to 1920 x 1080 2MP |
Frame rate |
Triple Stream / 1st stream: 30fps@1920×1080 |
Video streaming |
Triple stream with H.264/MJPEG, Adjustable frame rate, CBR/VBR in H.264 |
Pan/Tilt/Zoom |
Digital PTZ |
Corridor view |
Corridor view in H.264 (90degree/ 270degree) |
Image setting |
Brightness, contrast, Sharpness,Day & Night,Auto White Balance |
Security |
Password Protection, User access log, HTTPS encryption |
Supported protocol |
HTTP, HTTPS, FTP, SMTP, UPnP, DNS, DDNS, NTP, |
Intelligent video |
Object based Motion detection up with 12x 12 block |
Alarm events |
File upload via ftp, E-mail, Notification via email,SD Card. |
Video buffer |
5MB pre-alarm and 180 sec (max) post-alarm |
Firmware upgrade |
Remote upgrade via network |
API |
CGI Interface document, ActiveX Interface(ocx(dll) + document) |
Power Source |
DC12V/1.5A, PoE(Power over Ethernet): 802.3af-Optional |
Power Consumption |
Max. 3.5W |
Net Weight |
352g |
LED’s |
Power, Network Connection |
Dimension |
110mm(Dia.) x 47.5mm |
Operating Temperature |
-10 degree~50 degree Celsius(14F~122F) |
Storage Temperature |
-20 degree~60 degree Celsius(-4F~140F) |
Included Software |
NVR C/S (16 Channel), IP Installer (Windows only) |
Connection Layout
