Full gigabit 12-port unmanaged PoE switch

OVERVIEW

The ONV-POE33128PF series is a full gigabit unmanaged PoE fiber switch independently developed by ONV. It has 10*10/100/1000M RJ45 ports and 2*1000M SFP port slots, Port 1-8 can support IEEE802.3af/at PoE standard, single port PoE power up to 30W, Total power is 130W(at-250W). As a PoE power supply device, it can automatically detect and recognize the power receiving equipment that meets the standard and supply power through the network cable. it can automatically detect and identify the the electrical equipment that meets the standard and supply power to it through the network cable, devices including wireless AP, IP camera, IP telephone and other PoE terminal equipment etc. In addition, it is suitable for networking system of hotel, campus, dormitory and small&medium enterprise etc.

Unmanaged model, plug and play, no configuration, easy to use.

FEATURE

Full Gigabit access, gigabit TP/SFP port uplink

◇ All series supports “gigabit RJ45 port and Gigabit SFP port” combination, which enables users to flexibly build networking to meet the needs of various scenarios.

◇ Support non-blocking wire-speed forwarding.

◇ Support full-duplex based on IEEE802.3x and half-duplex based on backpressure.

Intelligent PoE power supply

◇ IEEE 802.3af/at PoE standard, without damaging non-PoE devices.

◇ 8*10/100/1000Base-T RJ45 ports, meeting the needs of security monitoring, teleconferencing system, wireless coverage, and other scenarios.

◇ Priority system for PoE port, it will supply power to the high priority level port first when the power budget is insufficient and avoid overwork of the device.

Stable and reliable

◇ CCC,CE, FCC, RoHS.

◇ Plug and play, no configuration, simple and convenient.

◇ Low power consumption, galvanized steel casing, The fan active cooling.

◇ Self-developed power supply, high redundancy design, providing a long term and stable PoE power output.

◇ The user-friendly panel, it can show the device status through the LED indicator of PWR, Link , L/A, PoE.

DIMENSION

ORDERING INFORMATION

PACKING LIST
