NAS Synology RXD1215sas

Mã sản phẩm: RXD1215sas

Mô tả: Reliable, scalable SAS storage expansion unit

Xuất xứ: Taiwan

Bảo hành: 12 tháng

Mã: RXD1215sas Danh mục: NAS Synology Từ khóa: RXD1215sas

Mô tả
Sản phẩm liên quan

RXD1215sas is a 12-bay storage expansion unit specifically designed to work with Synology’s RackStation RC18015xs+. When connected with RC18015xs+, it delivers the massive scalability and uncompromising resiliency that 24/7 businesses require.

Up to fifteen RXD1215sas can be connected to the dual RC18015xs+ computing nodes¹, accommodating massive scalability up to 180 drives and maximum raw storage beyond 1PB². The shared storage architecture eliminates the need for data replication over the network, in addition to drastically reducing deployment costs.

Hardware Specifications
Applied Models	RC18015xs+
Storage
Drive Bay(s)	12
Compatible Drive Type	3.5″ SAS HDD 2.5″ SAS HDD 2.5″ SAS SSD
Maximum Internal Raw Capacity	96 TB (8 TB HDD x 12) (Capacity may vary by RAID types)
Hot Swappable Drive
RAID Management through Synology DSM
External Ports
MiniSAS IN-port	2
MiniSAS OUT-port	2
Appearance
Size	88 mm x 430 mm x 692 mm
Weight	18 kg
Power
Power Recovery	Synchronized with the Synology RackStation
Power Supply Unit / Adapter	2 X 500W
AC Input Power Voltage	100V to 240V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption*	248 W (Access)
British Thermal Unit	846.21 BTU/hr (Access)
Redundant Power Supply
Temperature
Operating Temperature	5°C to 35°C (40°F to 95°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Relative Humidity	5% to 95% RH
Others
System Fan	60 mm x 60 mm x 4 pcs
Easy Replacement System Fan
Noise Level*	48 dB(A)
Certification	FCC Class A CE Class A BSMI Class A
Warranty	5 Years
Environment & Packaging
Environment	RoHS Compliant
Packaging Content	Main Unit X 1 Accessory Pack X 1 AC Power Cord X 2 Expansion Cable: MiniSAS X 2 Quick Installation Guide X 1
Optional Accessories	Synology RKS1314 – Rail Kit Sliding
