NAS Synology DS216

Mã sản phẩm: DS216

Mô tả: All-in-One, high-performance NAS server suitable for small offices and workgroups

Xuất xứ: Taiwan

Bảo hành: 12 tháng

Mô tả
Sản phẩm liên quan

DS216 DiskStation

Step up to an enhanced private cloud solution

Over View

DS216 is a feature-rich 2-bay NAS server, suitable for workgroups and office environment. With a hardware encryption engine, DS216 delivers speedy performance and protects data effectively, while boosting productivity.

DS216 delivers outstanding read/write performance with an average over 112 MB/s reading and writing speeds under RAID 1 configuration in a Windows environment. The built-in floating-point unit enhances the overall capability of the main CPU, and is particularly advantageous in speeding up thumbnail creation when uploading large amounts of photos or videos.

top-171

Specifications

Hardware Specifications
CPU
CPU Model	Marvell Armada 385 88F6820
CPU Architecture	32-bit
CPU Frequency	Dual Core 1.3 GHz
Floating Point
Hardware Encryption Engine
Memory
System Memory	512 MB DDR3
Storage
Drive Bay(s)	2
Compatible Drive Type	3.5″ SATA III / SATA II HDD 2.5″ SATA III / SATA II HDD 2.5″ SATA III / SATA II SSD
Maximum Internal Raw Capacity	16 TB (8 TB HDD x 2) (Capacity may vary by RAID types)
Maximum Single Volume Size	16 TB
Hot Swappable Drive
External Ports
USB 2.0 Port	1
USB 3.0 Port	2
USBCopy
File System
Internal Drives	EXT4
External Drives	EXT4 EXT3 FAT NTFS HFS+ (Read Only, with max. volume size 2TB)
Appearance
Size (Height x Width x Depth)	165 mm x 108 mm x 233.2 mm
Weight	1.3 kg
Others
RJ-45 1GbE LAN Port	1
Wake on LAN/WAN
System Fan	92 mm x 92 mm x 1 pcs
Fan Speed Mode	Cool Mode Quiet Mode
Wireless Support (dongle)
Brightness adjustable front LED indicators
Power Recovery
Noise Level*	18 dB(A)
Scheduled Power On/Off
Power Supply Unit / Adapter	60W
AC Input Power Voltage	100V to 240V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption*	15.48 W (Access) 7.2 W (HDD Hibernation)
British Thermal Unit	52.86 BTU/hr (Access) 24.58 BTU/hr (HDD Hibernation)
Environment Temperature
Operating Temperature	5°C to 40°C (40°F to 104°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Relative Humidity	5% to 95% RH
Certification	FCC Class B CE Class B BSMI Class B
Warranty	2 Years
Notes	Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s). Support for Wake on WAN needs switch and routers which recognize Magic Packet. Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
DSM Specifications
Storage Management
Maximum Internal Volume Number	256
Maximum iSCSI Target Number	10
Maximum iSCSI LUN	10
Supported RAID Type	Synology Hybrid RAID Basic JBOD RAID 0 RAID 1
RAID Migration	Basic to RAID 1
Volume Expansion with Larger HDDs	Synology Hybrid RAID RAID 1
Volume Expansion by Adding a HDD	Synology Hybrid RAID
File Sharing Capacity
Maximum User Accounts	2048
Maximum Groups	256
Maximum Shared Folder	256
Maximum Shared Folder Sync Tasks	2
Maximum Concurrent CIFS/AFP/FTP Connections	128
Windows Access Control List (ACL) Integration
NFS Kerberos Authentication
Log Center
Syslog Events per Second	100
Add-on Packages
Cloud Station Server
Maximum Concurrent File Transfers	128
Download Station
Maximum Concurrent Download Tasks	30
HiDrive Backup
Notes	The CPU and RAM usages were both under 80% when testing recommended client numbers. For tested models with expandable memory, the maximum amount of RAM was installed. Read-write SSD cache was enabled in 5-bay (and above) NAS models with 2 SSDs units installed. The performance of the mail system will slightly decrease in high-availability mode due to data synchronization between the two servers. Functions that were enabled in all of the tests above: anti-spam, anti-virus, DNSBL, greylist, content scan, full-text search (English only).
Media Server
DLNA Certification
PDF Viewer
SpreadSheet
Maximum Simultaneous Editing Users	35
Surveillance Station
Maximum IP cam (Licenses required)	16 (including 2 Free License)
Total FPS (H.264)*	480 FPS @ 720p (1280×720) 240 FPS @ 1080p (1920×1080) 150 FPS @ 3M (2048×1536) 60 FPS @ 5M (2591×1944)
Total FPS (MJPEG)*	240 FPS @ 720p (1280×720) 100 FPS @ 1080p (1920×1080) 60 FPS @ 3M (2048×1536) 30 FPS @ 5M (2591×1944)
Notes	Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
Video Station
Video Transcoding	Group 2
VPN Server
Maximum Connections	5
Environment & Packaging
Environment	RoHS Compliant
Packaging Content	Main Unit X 1 Welcome Note X 1 Accessory Pack X 1 AC Power Adapter X 1 AC Power Cord X 1 RJ-45 LAN Cable X 1
Optional Accessories	Camera License Pack VS360HD
