Antaira LNX-C500

Antaira’s Compact design LNX-C500 industrial unmanaged Ethernet switch is IP30 rated and DIN-Rail mountable. LNX-C500 is equipped with 5*10/100Tx RJ45 Ethernet ports; with a backplane speed of 1gbps. The small form factor of this industrial switch is 30%
smaller allowing for a more versatile implementation.

This model provides high EFT and ESD protection to prevent any unregulated voltage and is suitable for harsh environments. It also supports a standard operating temperature from -10° to 70° C.

LNX-C500 is a perfect industrial networking product to support any application such as power/utility, water wastewater treatment, oil/gas/mining, process control automation, security access control systems, and intelligent transportation systems.

• Compact Industrial Grade Design
• Supports 5*10/100Tx
• Supports Auto MDI/MDI-X Function
• Store-and-Forward Switching Architecture
• 8K MAC Address Table
• Surge Protection: 2,000 VDC Support
• ESD Protection: 6,000 VDC Support
• Redundant Power Input Design: 12~48VDC
• IP30 Rugged Metal Case Design
• DIN-Rail and Wall Mount Support
• Operating Temperature Range: -10° to 70° C
• 5-Year Warranty
