Antaira LNP-0800G-24-E-T

Antaira Technologies’ LNP-0800G-24-E-T is an 8-port industrial PoE+ unmanaged switch that supports 8*10/100/1000Tx Ethernet ports. LNP-0800G-24-E is a backwards compliant PoE+ switch that will support IEEE802.3af/at standards providing a maximum of 30 watts
per port with an input voltage of 12-36VDC.

Antaira’s LNP-0800G-24-E-T has been specifically designed for rugged and harsh environmental deployments. This model is housed in a hardened IP30 rated metal enclosure that includes DIN-rail and wall mounting hardware. There are two wide operating temperature
models for either a standard temperature range (STD: -10° to 60° C) or an extended temperature range (EOT: -40° to 70° C). LNP-0800G-24-E-T also provides high EFT and ESD protection for any industrial networking application within factory automation, ITS (including
on-vehicle), solar, security or any other outdoor environment.

• E-Mark certified for vehicle applications
• Supports 8-Port 10/100/1000Tx Gigabit RJ45
• 8-Ports of IEEE 802.3af/at (30 Watts/Port)
• Supports 9.6Kbytes Jumbo Frame
• Supports Auto MDI/MDI-X Function
• Store-and-Forward Switching Architecture
• Surge Protection: 2,000 VDC Support
• ESD Protection: 8,000 VDC Support
• Redundant Power Input Design: 12~36VDC
• Built-in 1 Relay Output for Fault Alarm
• IP30 Rugged Metal Case Design
• DIN-Rail and Wall Mount Support
• Operating Temperature Range: STD:-10° to 60°C, EOT:-40° to 70°C
• 5-Year Warranty
