Camera IP EYENOR ENC-HVD5F-30R-20 | Made in UK

MODEL

Model No.

ENC-HVD5F-30R-20

Type

2MP Starlight IP H.265 Vandal Proof Dome Camera

Image Sensor

1/2.9″, 2 Megapixel, Progressive scan CMOS

CAMERA

Lens

2.8 mm @ F1.6 (Optional 4mm)

Angle of View (H)

107.8°

Shutter

Auto/Manual, 1/6~1/100000 s

Min. Illumination

Colour: 0.003 Lux (F1.6, AGC ON)
0 Lux with IR

Day/Night

IR-Cut filter with auto switch (ICR)

Digital noise reduction

2D/3D DNR

S/N

>52dB

IR Range

Up to 30M IR range

Defog

Digital Defog

WDR

120dB

VIDEO & AUDIO

Video Compression

H.265, H.264, MJPEG

H.264 code profile

Baseline profile, Main Profile, High Profile

Frame Rate

Main Stream:2MP (1920×1080): Max. 30 fps;
Sub Stream:2MP (1920×1080): Max. 30 fps;
Third Stream:D1 (720×576): Max. 30 fps

9:16 Corridor Mode

Supported

ROI

Up to 8 areas

HLC

Supported

BLC

Supported

OSD

Up to 8 OSDs

Privacy Mask

Up to 8 areas

Motion Detection

Up to 4 areas

SMART

Behavior Detection

Intrusion, Crossing line, Motion detection

Exception Detection

Audio detection

Intelligent Identification

Face detection, Defocus, Scene Change

Statistical Analysis

People counting

General Function

Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication

AUDIO

Audio Compression

G.711

Two-way audio

Supported

Suppression

Supported

Sampling Rate

8 KHZ

NETWORK

Network Protocols

IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP

Compatible Integration

ONVIF, API

INTERFACE

Audio I/O

Input: impedance 35 kΩ; amplitude 2 V [p-p]

Output: impedance 600 Ω; amplitude 2 V [p-p]

Alarm I/O

1/1

Network

1 RJ45 10M/100M Base-TX Ethernet

GENERAL

Storage

Micro SD, Up to 128 GB

Network Storage

ANR

Power

12 V DC±25%, PoE (IEEE802.3 af)

Power consumption: Max 5.5W

Operating Temperature

-35°C ~ +60°C

Operating Humidity

10%~95% RH(Non-condensing)

Ingress Protection

IP67

Vandal Resistance

IK10

Dimensions

108.5×108.5x81mm

Weight

0.45Kg
